High Brightness Industrial Bar Type TFT-LCD Panel for Digital Signage & Outdoor Applications
Contact XIANHENG for QuotationThe AUO P483IVN02.0 is a 48.3-inch stretched bar TFT-LCD display panel developed by AU Optronics for demanding commercial and industrial environments. Featuring 700 cd/m² high brightness, AMVA3 technology, and a long-life WLED backlight with LED driver, this panel is ideal for continuous operation in digital signage and outdoor high-brightness displays.
| Brand | AUO |
| Model | P483IVN02.0 |
| Diagonal Size | 48.3 inch (Native Bar) |
| Resolution | 1920 × 320 |
| Brightness | 700 cd/m² (Typical) |
| Contrast Ratio | 4000:1 (Typical) |
| Viewing Angle | 89° / 89° / 89° / 89° |
| Display Mode | AMVA3, Normally Black, Transmissive |
| Response Time | 8 ms (G to G) |
| Backlight | WLED, 50K hours, With LED Driver |
| Interface | LVDS (2 ch, 8-bit), 51 pins |
| Input Voltage | 12V (Typ.) |
| Operating Temperature | -20 ~ 60 °C |
| Storage Temperature | -30 ~ 60 °C |
XIANHENG provides professional OEM and customization services for industrial LCD panels, including controller boards, touch integration, housing design, and brightness enhancement.
