| Brand | XIANHENG |
| Model P/N | XH101WUB-N80-500 |
| Diagonal Size | 10.1" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1920(RGB)×1200, WUXGA 224PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 216.806(W)×135.504(H) mm |
| Bezel Opening | - |
| Outline(mm) | 221.81 × 145.5 (H×V×D) |
| Treatment | Hard coating |
| Luminance | 500 cd/m² |
| Contrast Ratio | 900 : 1 (Typ.) (TM) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) Left / Right / Up / Down |
| Response | 30 (Typ.)(Tr+Td) ms |
| Good View at | Symmetry |
| Work Mode | ADS, Normally Black, Transmissive |
| Glass Thickness | - |
| Transmissivity | 3.85% (Typ.)(with Polarizer) |
| Color Depth | 16.7M 72% NTSC |
| Backlight | WLED |
| Mass-Used for | Industrial |
| Refresh Rate | 60Hz |
| Touchscreen | Without, optional |
| Driver IC list | Built-in COG 3 source chips |
| Signal Type | LVDS (2 ch, 8-bit) , 45 pins Connector |
| Voltage Supply | 3.3V (Typ.) |
| Max. RatingsStorage Temp. | : -30 ~ 85 °C Operating Temp.: -20 ~ 70 °C |
